Halogen Free Cross-linked PE lnsulated Wire
For use in ranges, water heaters, clothes dryers, rotisseries,cookers, toasters.
Leads for transformers, lighting, ballasts and motors.
Internal wiring of electric heating, gas heating, cooking equipment and hairdressing equipment.
Features
1. Temperature Rating:105 ?
2. Voltage Rating:300V
3. Standard: UL758?UL1581 & CSA C22.2 NO.210.2,IEC60754-2,RoHS
4. Tinned or bare, stranded or solid copper conductor, 32-10AWG.
5. Cross-linked flame retardant PE insulated.
6. Uniform insulation thickness to ensure easy stripping and cutting.
7. Passes UL VW-1 & CSA FT 1 vertical flame test

ENQUIRY!
SKU: UL3385 Category: Tag: Brand:

Description

Woer UL 3385 Halogen Free Cross-linked PE Insulated Wire For use in ranges of water heaters, clothes dryers, rotisseries, cookers, toasters. Leads for transformers, lighting, ballatss and motors. Internal wiring of electrical heating, gas heating, cooking equipment and hairdressing equiment.

Dimensions



AWG

Conductor
No./mm

Conductor
Dia.(mm)

Insulation
Thickness(mm)

Outer Dia.
(mm)

Maximum
Resistance
at 20? (Ω/Km)

Standard Length
(meter/ coil)

30

7/0.10

0.3

0.40±0.05

1.10±0.15

354

610

28

7/0.127

0.38

0.40±0.05

1.18±0.15

237

610

26

7/0.16

0.48

0.40±0.05

1.28±0.15

139

610

24

11/0.16

0.61

0.40±0.05

1.41±0.15

88.9

610

22

17/0.16

0.76

0.40±0.05

1.56±0.15

57.5

610

20

26/0.16

0.94

0.40±0.05

1.74±0.15

37.6

610

18

16/0.254

1.18

0.40±0.05

1.98±0.15

23.8

305

16

26/0.254

1.50

0.40±0.05

2.30±0.15

15.1

305

Manufacturer:Electronic Components
Datasheet:Woer/UL3385.pdf
