Description
Specifications
Diameter : 3.0mm
LED Type : 3mm Standard LED
Illumination Type : Single Colour
Light Colour : Green
Light Wavelength : 568.0nm
Lens Type : waterclear
Viewing Angle : 20.0
Intensity : 500.0mcd
Vf (typ) – Typical Forward Voltage : 2.1V
If (typ) – Typical Forward Current : 20.0mA
If (max) – Maximum Forward Current : 30.0mA
Resistor for 5VDC : 150.0Ohm
Resistor for 9VDC : 360.0Ohm
Resistor for 12VDC : 510.0Ohm
Manufacturer Part Number: ZD0122
Manufacturer: Electronic Components
