Description
37103004 Socomec FUSERBLOC Compact series rotary disconnect switch, fusible, Class J, load break capable, 3-pole, 600 VAC, 30A, 100kA SCCR, DIN rail or panel mount, UL 489 rated, front operated, accepts 5 x 5mm size shaft.
SOCOMEC 37103004 FUSERBLOC CD J 3X30A
– Accepts Class CC, J and L fuses.- Very high short circuit protection, up to 200 kAIC.- Used of glass fiber renforced polyester for both high mechanical and thermal resistance.- Make and break under load conditions to provide safety of person and equipment.- Large range of connection accessories and mounting brackets for quick and easy installation.- Double breaking per pole (top and bottom) providing extra protection.- Compact solution available: FUSERBLOC CD.
UPC: 78200139102
Part Number: 37103004
UNSPSC: 39122233
Retail Price: $598.46 / ea
Net Price: $179.54 / ea
Availability: 3 ea i
Quantity ea Add to Cart
Checkout
Features / Benefits
The absolute service entrance disconnect protection
The double phase isolator (upstream-downstream of the fuse) and fully visible isolation guarantee the safety of people and equipment against overcurrents.
High breaking capacity fuses (200?kA rms) provide protection against overloads and short-circuits.
Data centre – Power for busway and tap-off##NewItem##Healthcare – Critical power for medical imaging##NewItem##Industry – Protection for drives and motors##NewItem##Industry – Insulation monitoring##NewItem##Building – Power availability for life safety
Specifications
Catalog Number 37103004
Auxiliary Contacts / Electrical Characteristics A600
Category FUSE COMBINATION SWITCH
Conformity To Standard #1 UL489
Conformity To Standard #2 CSA-C22.2 No. 5
Conformity To Standard #3 Class 4652 06
Country of Origin FR
DC FLA Motor Max. / 125 VDC 03/25
DC FLA Motor Max. / 250 VDC 5/20
Description (30 Char.) FUSERBLOC CD J 3X30A
Description (70 Char.) Fusible discon switch FUSERBLOC-Ext&Dir F/L R&L OP-30A-3P-UL-Fuse J
Endurance (number Of Operating Cycles) 10000
FLA 1 Ph Motor Max. / 120 VAC 2/24
FLA 1 Ph Motor Max. / 220-240 VAC 5/28
FLA 1 Ph Motor Max. / 240 VAC 5/28
FLA 3 Ph Motor Max. / 220-240 VAC 7.5/22
FLA 3 Ph Motor Max. / 440-480 VAC 15/21
FLA 3 Ph Motor Max. / 600 VAC 20/22
FUNCTIONS FUSERBLOC fusible disconnect switches are heavy duty switches that break and make power circuits on and off load.The switches employ double break contacts per pole that ensure complete isolation of the fuse when the switch is in the OFF position. These switches are extremely durable and are tested and approved for use in the most demanding applications.
Family Name FUSE COMBINATION SWITCH
GTIN/EAN 3596031190027
MAX FUSE RATING 30
Market Segment Data center##NewItem##Healthcare Facilites##NewItem##Industry##NewItem##Buildings
Max. Connection Section / AWG #10
Min Order Qty 1
Min. Connection Section / AWG #14
Nominal Current Rating (A) 30
Operating Temperature -4 … +122F / -20 … +50C
Operating Torque 31/3.5
Operation Voltage 2 P – 3/4 P 600VAC
PDW CSS HARMONIZED TARIFF CODE 8536308000
Product Description SOCOMEC 37103004 FUSERBLOC CD J 3X30A
Product Name FUSERBLOC UL
Product Short Description Fusible disconnect switches with UL and CSA standards
Short Circuit Rating At 600 VAC 100
Storage Temperature -40 … +158F / -40 … +70C
TYPE OF FUSE J
UNSPSC Code 39122233
