Description
Mersen A4BQ6000-SEAFuse Time Delay Class L 200kA AC/100kA DC 600VAC 500VDC 6000A Remote Trigger, Cylindrical Cartridge Bolt Mount CSA, UL
Mersen A4BQ6000-SEA-1 – Amp-Trap A4BY fuses have been the industry’s favorite when it comes to protecting service entrance equipment, feeder circuits, and circuit breakers. The A4BY is a 100percent rated device and may be applied at continuous currents up to its ampere rating. A 4-second minimum time delay at 500percent rating allows the A4BY to pass normal current surges and to coordinate with ground fault relays.
Product Category: Industrial & Electrical Fuses
Product: Class L Fuses
Current Rating: 6 kA
Voltage Rating AC: 600 VAC
Fuse Type: Time Delay / Slow Blow
Voltage Rating DC: 500 VDC
Interrupt Rating: 100 kA, 200 kA
Body Style: Cartridge Blade Fuses
Mounting Style: Holder
Termination Style: Knife Blade
Indicator Style: Trigger Actuator
Brand: Mersen
Length: 273 mm
Product Type: Industrial Power Fuses
Subcategory: Fuses
Type: Power Fuses
Width: 146 mm
Amp-Trap 2000 A4BQ fuses are 20% more current limiting than any other Class L fuse
300kA interrupt rating – self-certified, UL witnessed tests
Pure Silver Links ensure lowest let-thru current and longer fuse life
High-grade silica filler ensures fast arc quenching
Applications – Large Motor and Transformers, Lighting & Heating, Mains, Feeders, Branch Circuits
UL / CSA
Technical Description:
Class L Type; 10-3/4 Inch; UL 248-10, CSA C22.2 Approval; 600 VAC Voltage Rating; 7-1/8 Inch Diameter; 200 Kiloampere Interrupting Rating; 6000 Ampere Current Rating; Blade Terminal Type; 4 Sec Time Delay (at 500 Percent Rated Load) Characteristics
