Description
CCV2150 Cutler-Hammer Eaton Type CCV Tenant Main Circuit Breaker,Tenant main circuit breaker,150 A,10 kAIC,Two-pole,120/240 V,#2/0 AWG-300 kcmil Cu/Al,CCV,Type ECC unit enclosures
The Circuit Breaker is a high-performance solution designed to protect electrical systems in residential and commercial settings. With a 150 A rating and support for 120/240 V AC, this breaker is ideal for single-phase applications. It features 2 poles and accommodates wire sizes from 2/0 AWG to 300 Kcmil, allowing for flexible installation. The compact design measures 5.4 inches in height, 7.7 inches in length, and 4.5 inches in width. Weighing 2.9 lb, this CCV breaker offers durability and consistent performance for a wide range of electrical systems.
Key Features:
150 A rating with 2-pole, single-phase configuration
Operates at 120/240 V AC for versatile use
Compatible with 2/0 AWG to 300 Kcmil wire sizes
CCV breaker type for dependable protection
Durable and compact design weighing 2.9 lb
Quick Specs
Manufacturer
Eaton
Manufacturer’s Part Number
CCV2150
Description
CCV BRKR 150A/2 Pole 120/240V 10K
Circuit Breaker, 150 A, 5.4 In Overall Height, 7.7 In Overall Length, 4.5 In Overall Width, 2 Poles, 1 Phase, #2/0 Awg to 300 Kcmil Wire Size, 120/240 V Ac, CCV Breaker, 2.9 LB
Slang Terms
Categories
Modular & Group Metering – Main Circuit Breaker Modules
Classification
Breaker Enclosures With or Without Breaker
UNSPSC
39121601 – Circuit breakers
UPC/GTIN
786685368450 / 00786685368450
Weight per unit
2.9 (lbs/each)
