Description
CH2125 Cutler-Hammer Eaton CH Thermal magnetic circuit breaker, Type CH 3/4-Inch standard circuit breaker, 125 A, 10 kAIC, Two-pole, 120/240V, CH, Common breaker trip, #10-1/0 AWG Cu/Al, CH, Type CH Loadcenters
Eaton / Cutler-Hammer Plug-On Circuit Breaker Its Compact And Easy to Install two pole circuit breaker features thermal magnetic molded case for extra protection circuit breaker has a current rating of 125 amps and voltage rating of 120/240 Vac it is a common trip breaker that has AIC rating of 10000 ampere and it can accommodate a wire size of 10-1/0 AWG at load circuit breakers is UL 489 listed and Csa certified.
Eaton’s residential CH circuit breakers provide premium overload protection. The Type CH circuit breakers trip to the OFF position, eliminating nuisance callbacks. The CHF family also includes a trip flag to differentiate between a trip and the breaker being turned off. The thermal-magnetic trip curve avoids nuisance tripping on mild overloads while reacting almost instantaneously to severe short-circuit conditions. Multiple breakers have an internal common trip connection to operate all poles simultaneously. Handles are marked with ON-OFF indication and ampere rating of the breaker.
Specifications:
Product Name: Type CH 3/4-inch Standard Circuit Breaker
Certifications: UL 489
Catalog Notes: Two-Pole 120/240V Common Trip Requires Two 3/4-Inch Spaces
Interrupt Rating: 10 Kaic:
Type: Type Ch 3/4-Inch Standard Circuit Breaker
Wire Size: #10-1/0 Awg Cu/Al:
Used With: Type CH Loadcenters
Main Circuit Breaker: CH
Voltage Rating: 120/240V
Amperage Rating: 125A
Trip Type: Common
Number Of Poles: Two-pole
Voltage Rating: 120/240V
Amperage Rating: 225A
Number Of Poles: Two-pole
Authentic Eaton/Cutler-Hammer Product
BrandEATON
Amperage Rating125 A
Country of OriginDO
Dimensions3-3/4 in L x 2-1/2 in W x 2-3/4 in H
Enclosure TypeNEMA 1/3R
Interrupt Rating10 kA
Manufacturer NameEaton
Mounting TypePlug-On
Number of Poles2
Phase1, 1 ph
Temperature Rating60 to 75 deg C
Trip TypeCommon/Thermal Magnetic
TypeType CH Standard
Voltage Rating120/240 V AC, 120/240 VAC
Wire Size10 to 1/0 AWG
Specs: CH2125
