Description
Transistor, N-Channel FET. Max voltage: 50V. Max current: 15Amp. Gain: 75 watt. Package: TO-220. P/N: MTP15N06E. Note: TMOS Power Field Effect Transistor, 0.1 Ohm. Operating temperature: -65 to 150 Deg C.
SPECIFICATIONS
Part #: MTP15N06E
Part Category: Transistors
Manufacturer: Motorola Solutions, Inc.
Description: Power Field-Effect Transistor, 15A I(D), 60V, 0.15ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB
Status Discontinued
Case Connection DRAIN
Configuration SINGLE WITH BUILT-IN DIODE
Drain Current-Max (Abs) (ID) 15.0 A
Drain Current-Max (ID) 15.0 A
Drain-source On Resistance-Max 0.15 ohm
DS Breakdown Voltage-Min 60.0 V
Feedback Cap-Max (Crss) 100.0 pF
FET Technology METAL-OXIDE SEMICONDUCTOR
JEDEC-95 Code TO-220AB
Manufacturer:Motorola
Datasheet:Motorola/MTP15N06E.pdf
