Description
Enphase SC200D111C240US01 IQ System Controller 3, With RSD Switch and 4-Pole Breaker, 200A Capacity, Neutral-Forming Transformer, Microgrid Interconnect Device (MID), Intelligent Load Control, For Systems w/o Generator, 120/240VAC, NEMA 3R, UL 1741-SB
The SC200D111C240US01 IQ System Controller 3 provides microgrid interconnection device (MID) functionality by automatically detecting and seamlessly transitioning the home energy system from grid power to backup power in the event of a grid failure. It consolidates interconnection equipment into a single enclosure and streamlines grid-independent capabilities of PV, storage by providing a consistent, pre-wired solution for residential applications. The SC200D111C240US01 IQ System Controller 3 supports up to 80 KWh of battery without generator support.
The Enphase IQ System Controller 3/3G connects the home to grid power, the IQ Battery system, and solar PV. It provides microgrid interconnect device (MID) functionality by automatically detecting and seamlessly transitioning the home energy system from grid power to backup power in the event of a grid failure. It consolidates interconnection equipment into a single enclosure and streamlines grid-independent capabilities of PV and storage installations by providing a consistent, pre-wired solution for residential applications.
IQ Series Microinverters
The high-powered smart grid-ready IQ Series Microinverters (M Series, IQ6, IQ7, and IQ8 Series) dramatically simplify the installation process
Product Specifications | Download
IQ Battery 5P
Fully integrated AC battery system. Includes six field-replaceable IQ8D-BAT microinverters
IQ Combiner 5/5C
Consolidates PV interconnection equipment into a single enclosure and streamlines IQ Series Microinverters and IQ Gateway installation by providing a consistent, pre-wired solution for residential applications
IQ Load Controller
Helps prioritize essential appliances during a grid outage to optimize energy consumption and prolong battery life
Easy to Install
Connects to service entrance’ or main load center
Includes neutral-forming transformer
Mounts on single stud with centered brackets>
Provides conduit entry from bottom, left, or right
Includes color-coded wires for ease of wiring System Shutdown Switch
Integrates hold-down functionality to eliminate the need for hold-down kits and special breakers
Flexible
Can be used for Sunlight Backup, Home Essentials Backup, or Full Energy Independence
IQ System Controller 3 integrates with IQ Battery 5P
IQ System Controller 3G integrates with select AC standby generators. See Generator Integration Tech Brief for a list of generators
Provides a seamless transition to backup
Safe and Reliable
System Shutdown Switch can be used to disconnect PV, battery, and generator systems
It acts as a rapid shutdown initiator of grid-forming IQ8 PV Microinverters for safety of maintenance technicians/first responders
10-year limited warranty
NOTE: This unit DOES NOT support Generator Integration. Use the SC200D111C240US01 IQ System Controller 3 for all new installs using IQ8 Series Microinverters.
Includes
(1) IQ System Controller 3
(1) Color Coded Pre Wired-System Shutdown Switch
(1) Wall-mounting Bracket
(1) Pre-Installed 4 Pole Circuit Breaker
(1) Accessories Kit
