Description
TM3DQ16RG Schneider Electric discrete output module, Modicon TM3, 16 relay outputs, spring, 24V DC, DIN Rail Screw Terminal for Modicon TM3 Series. This product is part of the Modicon TM3 range, an offer of expansion I/O modules for Modicon M221, M241, M251 and M262. The discrete output module provides 16 relay outputs with positive or negative logic. It is an output module with an output voltage of 240V AC, 30V DC and a current consumption of 75mA at 24V DC via bus connector. This product is capable of controlling variable speed drives or any device equipped with a current or voltage input. There is an insulation between output and internal logic at 2300V AC, outputs at 750V AC, output groups at 1500V AC. It is furnished with removable spring terminal for electrical connection with pitch 3.81mm adjustment for outputs. It offers mechanical durability of 20 million cycles. It is an IP20 rated product. Its dimensions are 27.4mm (Width) x 84.6mm (Depth) x 90mm (Height). It weighs 0.130kg. This product is certified by CE, CULus and C-Tick. It meets EN/IEC 61131-2 and EN/IEC 61010-2-201 standards. This module is compatible with Modicon M262, Modicon M241, Modicon M251 and Modicon M221 logic controller. It supports top hat type TH35-15, top hat type TH35-7.5 rail conforming to IEC 60715 and plate or panel with fixing kit mount. Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data and the power supply when assembling the Modicon TM3 modules with logic controllers. Boost the performance of your controller with the Modicon TM3 I/O system specially designed for the Modicon M221, M241 and M251 logic controllers.
Specifications
Primary brand
Schneider Electric
Secondary brand
Modicon
Main function
I/O unit
Product series / family name
Modicon TM3
Sub-range name
Modicon TM3 I/O modules
Functions
AC/DC digital output module
Supply voltage (AC)
240Vac
Supply voltage (DC)
19-30Vdc (24Vdc nom.)
Display
1 green LED (for output status per channel)
Connection type
removable spring term. blck.
Mounting mode
symmetrical rail or pnl. mounting
Digital outputs
16 x digital outputs (2A; NO rly. contact outputs)
Degree of protection
IP20
Ambient air temperature for operation
(horizontal installation) +14…+131°F / -10…+55 °C
(vertical installation) +14…+95°F / -10…+35 °C
Ambient air temperature for storage
-13…+158°F / -25…+70 °C
Humidity
10-95% (without condensation in operation and in storage)
Current consumption
0mA (at 24Vdc via bus connector at state off)
75mA (at 24Vdc via bus connector at state on)
Technical compatibility with
Modicon M221 logic controllers
Modicon M221 Book logic controllers
Modicon M241 logic controllers
Modicon M251 logic controllers
Modicon M262 logic/motion controller
TM3BC bus coupler modules
Order code / Manufacturer SKU
TM3DQ16RG
Manufacturer product status
Commercialized
Compliant with standard(s)
IEC 61131-2
IEC 61010-2-201
Location of origin
Taiwan (TW)
Benefits
Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism
A bus expansion connector is used to distribute data (data synchronization) and provide power during assembly on the bus coupler module and on the Modicon M221 / M221 Book / M241 / M251 logic controllers and Modicon M262 logic/motion controller
